Description
| Chassis | |||||||||||
| Steel Material | T700 high tensile structure steel | ||||||||||
| Dimension | 12,160mmx2,500mmx1,385mm (L.W.H) | ||||||||||
| Axle | YUEK 13T 3 Pcs | ||||||||||
| Curb Weight | 6,000kg | ||||||||||
| Rated Payload | 60,000kg | ||||||||||
| Wheel Base | 7,795mm + 13,10mm + 1,310 mm | ||||||||||
| Tread Base | 1,840mm | ||||||||||
| Tire brand/model/quantity | ANNAITE Brand 11.00R20 12pcs | ||||||||||
| Rim | ZHENGXING 7.5 12Pcs | ||||||||||
| Suspension | Rigid Suspension High Tensile | ||||||||||
| Front/Rear suspension | 750/995 | ||||||||||
| Main Beam | T700, 450mm thickness | ||||||||||
| Upper Steel | T700 10mm | ||||||||||
| Down Steel | T700 12mm | ||||||||||
| Web Steel | T700 6mm | ||||||||||
| Base board steel/faceplate steel | 3mm steel checkered plate | ||||||||||
| Landing gear | JOST 28T Single action Double speed | ||||||||||
| Kingpin | JOST 90# | ||||||||||
| Spring plate | 13mm x 8 | ||||||||||
| Quality Guarantee | One year, wearing parts for 3 months | ||||||||||
Brake System |
|||||||||||
| Dual chamber Front axle 30”chamber Rear axle 30/30”chamber | |||||||||||
| Electrical System | |||||||||||
| Voltage 24V LED 7 cores socket Reflection Light 2 units of side lights, rear lights,width lights | |||||||||||
| Accessories and Tools | |||||||||||
| 2 units U bolt, tie rod and side lights
12 units Container Twist Lock 24 units Tether Lock 2 units Spare Tire Frame 2 sets Tool box 1 set wrench 2 sets Air reserver |
|||||||||||
| Surface Painting Treatment | |||||||||||
| Painting: The frame is polished totally. Zinc-rich primer+face color as your need, with the reflecting marking, with reflection lights. | |||||||||||
| Production Time: 30 workdays | |||||||||||
| Payment Terms: 30% down payment by T/T, 70% balance payment by T/T before shipment. | |||||||||||
